Workflow Sheet for Epson L1800 1390 and Artisan 1430 Mainboard Wiring (CB53 MAIN and MAIN-B)
Roll over image to zoom in
Workflow Sheet for Epson L1800 1390 and Artisan 1430 Mainboard Wiring (CB53 MAIN and MAIN-B)
Availability:
In-Stock
Workflow sheet for connect all wires (and FFC cables) on the mainboard of Epson Artisan 1430 and L1800. Both Mainboards CB53MAIN and CB53 MAIN-B are covered. The relay board CA58...
$5.99
SKU:
WorkFlow-EP-L180013901430-MainBoardWire
Categories:
Tags:
Workflow sheet for connect all wires (and FFC cables) on the mainboard of Epson Artisan 1430 and L1800.
- Both Mainboards CB53MAIN and CB53 MAIN-B are covered.
- The relay board CA58 SUB-B is also covered.
- We try to put everything in a sequence so you can follow the steps and put the messy cables back to where they belong.
Instruction:
